ULTRA-LOW NITROGEN TECHNOLOGYThe core low-nitrogen furnace technology + fully
ULTRA-LOW NITROGEN TECHNOLOGY
The core low-nitrogen furnace technology + fully automatic low-nitrogen burner* is adopted to achieve boiler tail gas nitrogen oxide emissions ≤30mg/m³, which meets national environmental protection requirements.
FIRE TUBE STRUCTURE
It adopts fire tube structure and water-wrapped fire design, which has low requirements on water quality and is easy to repair and maintain in the later stage..
AUTOMATIC CONTROL
With the fully automatic control system, you only need to set the required pressure/temperature and other parameters to achieve fully automatic control: automatic start and stop of the burner, automatic water replenishment and other operations; reduce the labor intensity of boiler operators and reduce misoperation caused by human factors.
HEAT RECOVERY
The flue gas waste heat recovery device* is installed after the boiler to reduce the exhaust gas temperature and improve the thermal efficiency of the boiler; it also reduces fuel consumption and saves operating costs.
*：Optional configuration
| MODEL | BOILING WATER(T/h) | RATED INLET AND OUTLET WATER TEMPERATURE(℃) | EFFICIENCY(%) | CONSUMPTION (Diesel kg/h) | CONSUMPTION (Nature gas Nm³/h) |
| CLHSV0.1-85/60-Y(Q) | 0.1 | 95-100 | ≥93% | 5-8 | 8-10 |
| CLHSV0.2-85/60-Y(Q) | 0.2 | 95-100 | ≥93% | 8-10 | 12-15 |
| CLHSV0.3-85/60-Y(Q) | 0.3 | 95-100 | ≥93% | 12-15 | 15-20 |
| CLHSV0.5-85/60-Y(Q) | 0.5 | 95-100 | ≥93% | 20-25 | 25-30 |
| CLHSV0.7-85/60-Y(Q) | 0.7 | 95-100 | ≥93% | 25-30 | 30-35 |
| CLHSV1-85/60-Y(Q) | 1 | 95-100 | ≥93% | 40-45 | 45-55 |
| CLHSV1.5-85/60-Y(Q) | 1.5 | 95-100 | ≥93% | 50-60 | 60-75 |
| CLHSV2-85/60-Y(Q) | 2 | 95-100 | ≥93% | 65-75 | 80-100 |
| CLHSV3-85/60-Y(Q) | 3 | 95-100 | ≥93% | 100-120 | 120-150 |
FUEL OPTIONS INCLUDE: LPG, LNG, CNG, LIGHT DIESEL, HEAVY OIL AND MORE.
Note: Due to technical updates, we cannot display all the latest parameters here. If we make changes, we will not modify them here. We have more models for you to choose from. If your needs are not found here, please contact us.
